SKYDANCE SYSTEMS CATALOGUE FAQ RF 4 channels RGBW, RGB, CCT and single-colour LED controller. It can be matched to all RF single-colour, CCT, RGB and RGBW remote controls (up to 10 remote controls). It is possible to connect 4 external push switches to turn on/off and dim each channel. After selecting the light CCT, RGB or RGBW it allows to set the push switches to adjust every kind of LED strip.
For more information, please log in to the website and consult the manual, if available.
Technical parameters:
- Input voltage: 12-48V
- Load current: 5A
- Channels: 4
- Max power: 240-960W
- Max total output: 20A
- Input signal: RF 2.4GHz + Push Dim
- Output signal: CV PWM
- Connector: terminal block
- Working temperature: -30°C ~ +55°C
- Dimensions: 175x45x27 mm
Synchronization:
- Press briefly the match key on the receiver: within 5 seconds press any key on the remote control or press the key of the desired zone in case of multizone remote control
- Keep pressing the match key (5s): in this way every matching with the remote control will be deleted and the light will keep its current state
- Keep pressing the match key (10s): the default parameters will be restored.
ATTENTION: Wi-Fi connection can cause interference with the controller and, as a consequence, significantly reduce its range.
The use of shielded cables is recommended when installed near to cables plugged into the mains.
