Led strip was built with Honglitronic leds, version HL-AM-2835H421W-S1-08-HR3-3SDCM. The 3step LED allows to install or replace LED strips having the same colour temperature without seeing different shades of colour even for different product batches. For further information please consult LED datasheet.
The led strip K52-40s-060822 is flexible and features a double-sided tape on its back side for quick installation even on curved surfaces.
Tech specs:
- 2835 LED
- Lumens: 1400 lm/m
- Efficiency: 110 lm/W
- Strip LED colour temperature: 4000K 3step
- Power consumption 14,4 W/m (72W), 24V (+0%, -15%)
- Dimmable LED strip with 300 leds (60 leds/m)
- Led strip cuttable every 6 leds (every 10cm). Length 5 m, width 12 mm, height 4 mm
- Water protection: IP65
- PCB colour: White
- Double sided adhesive tape type: 3M 5604A VHB
- Working temperature: -10°C ~ +50°C
For a perfect adhesion of the double-sided tape the temperature both of the LED strip and the surface where it is installed should be between 21 and 38°C. The LED strip will be totally fixed after 72 hours approximately. The double-sided adhesive does not guarantee a seal on painted surfaces.
The energetic class refers to the light source installed inside. The luminous flux is lower and depends on the kind of IP protection.
